Looking to install the stock ROM on your Vivo V20? This comprehensive guide provides direct download links for the PD2039F firmware flash file and clear, step-by-step instructions to get your phone back on track.
Use this firmware file to effectively reset your phone, fix bootloop issues, bypass password locks, resolve device freezing, and address numerous other software problems.
Vivo V20 Quick Specifications
- Release Year:
- 2020
- Display:
- 6.44-inch AMOLED, 1080 x 2400 pixels (~409 ppi density)
- Processor:
- Qualcomm Snapdragon 720G, Octa-core
- RAM:
- 8GB
- Storage:
- 128GB or 256GB internal, expandable via microSDXC
- Operating System:
- Launched with Android 11, Funtouch OS 11
- Rear Camera:
- Triple camera system with 64 MP wide, 8 MP ultrawide, and 2 MP depth sensors
- Front Camera:
- 44 MP with autofocus
- Battery:
- 4000 mAh non-removable, with 33W fast charging
- Connectivity:
- 4G LTE, Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 5.1, USB Type-C 2.0
- Other Features:
- Under-display fingerprint sensor, 3.5mm headphone jack
The Vivo V20 (PD2039F) is a mid-range smartphone from 2020, notable for its powerful 44MP autofocus selfie camera. It features a sharp AMOLED display, a Snapdragon 720G processor, and a triple rear camera system, all powered by a 4000 mAh battery with 33W fast charging.
Vivo V20 (PD2039F) Firmware Download Links
| Filename | Download Link |
|---|---|
| PD2039F_EX_A_6.71.2_210903183124_LA.QSSI.12.0.R1.11.00.00.782.015_System_Split.zip | Download A_6.71.2 (MediaFire) |
| PD2039F_EX_A_6.70.49_210903183124_LA.QSSI.12.0.R1.11.00.00.782.015_System_Split.zip | Download A_6.70.49 (MediaFire) |
| PD2039F_EX_A_1.73.7_vivo_qcom_LA.UM.9.1.r1-04900-SMx1-common_split.gz | Download A_1.73.7 (MediaFire) |
| PD2039F_EX_A_1.73.2_vivo_qcom_LA.UM.9.1.r1-04900-SMx1-common_split.rar | Download A_1.73.2 (Google Drive) |
| Vivo_V20_PD2039F_EX_A_1.19.8_LA.UM.9.1.R1-04900-SMX1-Common_Split_QPST.zip | Download A_1.19.8 (Google Drive) |
Important Safety Notice
- Backup Your Data: This process will completely erase all data on your phone.
- Use the Right Files: The firmware must be an exact match for your Vivo V20 (PD2039F). Flashing the wrong firmware can permanently brick your phone.
- EDL Mode is Crucial: The phone must be in Emergency Download (EDL) mode for QPST to work.
Prerequisites: All Necessary Files and Tools
- A Windows PC: QPST and QFIL are Windows-based tools.
- USB Cable: Use a high-quality USB data cable, preferably the one that came with the phone.
- QPST Package: Download and install the complete QPST package. This usually includes QFIL.
- Qualcomm USB Drivers: Install the correct Qualcomm QDLoader USB drivers on your PC. You might need to disable Windows Driver Signature Enforcement to install them.
- Firmware File: You will need the correct firmware for your device, downloaded from the table above.
Detailed Step-by-Step Instructions
Step 1: Prepare Your PC and Files
The first step is getting everything ready on your computer. Locate the firmware file you downloaded for the Vivo V20, which should be named something like[PD2039F_EX_A_6.71.2_210903183124_LA.QSSI.12.0.R1.11.00.00.782.015_System_Split.zip], and extract its contents to a new folder.
After extracting, install the Qualcomm QDLoader drivers and the QPST tool. A reboot of your PC after installing drivers is highly recommended to prevent connection issues.
Step 2: Enter Emergency Download (EDL) Mode on the Vivo V20
This is the most important step for this specific model. Follow the instructions below precisely.
1. ADB Method (Simplest, if Device Boots)
If your phone still powers on and you have USB debugging enabled:
This will restart the phone directly into EDL mode
2. Fastboot Method (If Bootloader Access is Available)
Boot your device into the bootloader, then run:
This command should trigger EDL mode, too
Step 3: Flash the Firmware with QFIL
With your Vivo V20 now in EDL mode and connected to your PC, it’s time to launch the flashing tool.
- Launch QFIL: Open the QFIL application as an administrator. You should see your device listed as “Qualcomm HS-USB QDLoader 9008” at the top. If not, re-check your drivers and EDL connection.
- Select the Programmer: In QFIL, click “Browse” next to the “Select Programmer” field. Navigate to your extracted firmware folder and select the programmer file (it usually contains “firehose” in the name, e.g.,
prog_emmc_firehose.mbn). - Load the XML Files: Click on “Load XML”. This will prompt you to select the
rawprogram0.xmlfile, and immediately after, thepatch0.xmlfile. - Start the Flash: Double-check that all paths are loaded correctly, then click the “Download” button. The flashing process will begin. Do not disconnect the device under any circumstances.
- Completion: Wait patiently until the progress bar turns blue and the status message reads “Download Succeed.”
Step 4: Reboot Your Phone
Now that the new firmware is installed, it’s time to bring your Vivo V20 back to life. Unplug the device from your PC and press and hold the Power key until the screen lights up and the boot animation appears.
The first boot will take longer than usual as the new system is initialized. Be patient, and you will eventually be greeted by the initial setup screen.
